AIR CONDITIONING: FRONT EVAPORATOR TEMPERATURE SENSOR: INSTALLATION

INSTALLATION

1. INSTALL EVAPORATOR TEMPERATURE SENSOR





(a) Install evaporator temperature sensor as shown in the illustration.





NOTE:
- Be sure to insert the sensor only once because reinserting it will not allow it to be firmly secured.
- When reusing the evaporator, insert the sensor one row next to the one that has been used previously (X in the illustration).
- After inserting the sensor, do not apply excessive force to the wire.
- Directly insert the sensor until the edge of the plastic case "a" comes into contact with the evaporator "b".

2. INSTALL NO. 1 COOLER EVAPORATOR SUB-ASSEMBLY Reassembly
3. INSTALL COOLER EXPANSION VALVE Reassembly
4. INSTALL BLOWER ASSEMBLY Installation
5. INSTALL NO. 3 AIR DUCT SUB-ASSEMBLY Installation
6. INSTALL NO. 2 AIR DUCT SUB-ASSEMBLY Installation
7. TEMPORARILY TIGHTEN AIR CONDITIONING UNIT Installation
8. INSTALL INSTRUMENT PANEL REINFORCEMENT ASSEMBLY (for Manual Transaxle) Installation
9. INSTALL INSTRUMENT PANEL REINFORCEMENT ASSEMBLY (for Automatic Transaxle) Installation
10. INSTALL AIR CONDITIONING UNIT Installation
11. INSTALL INSTRUMENT PANEL WIRE Installation
12. CONNECT DRAIN COOLER HOSE Installation
13. INSTALL POWER STEERING ECU ASSEMBLY Installation
14. INSTALL REAR NO. 2 AIR DUCT Installation
15. INSTALL INSTRUMENT PANEL BRACE SUB-ASSEMBLY Installation
16. INSTALL RELAY BLOCK ASSEMBLY Installation
17. INSTALL NO. 1 AIR DUCT SUB-ASSEMBLY Installation
18. INSTALL CENTER INSTRUMENT PANEL TO COWL BRACE Installation
19. INSTALL LOWER DEFROSTER NOZZLE ASSEMBLY Installation
20. INSTALL REAR NO. 1 AIR DUCT Installation
21. INSTALL REAR NO. 3 AIR DUCT Installation
22. INSTALL STEERING COLUMN ASSEMBLY Installation
23. TURN FRONT WHEELS FACING STRAIGHT AHEAD
24. CONNECT NO. 2 STEERING INTERMEDIATE SHAFT ASSEMBLY Installation
25. INSTALL COLUMN HOLE COVER SILENCER SHEET Installation
26. TURN FRONT WHEELS FACING STRAIGHT AHEAD
27. INSTALL TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE SUB-ASSEMBLY Installation
28. INSTALL STEERING COLUMN COVER Installation
29. ADJUST SPIRAL CABLE Installation
30. INSTALL STEERING WHEEL ASSEMBLY Installation
31. INSTALL STEERING PAD Installation
32. INSTALL LOWER INSTRUMENT PANEL SUB-ASSEMBLY Installation
33. INSTALL ANTENNA CORD SUB-ASSEMBLY Installation
34. INSTALL HOOD LOCK CONTROL LEVER SUB-ASSEMBLY Installation
35. INSTALL NO. 1 INSTRUMENT CLUSTER FINISH PANEL SEAL Installation
36. INSTALL RADIO BRACKET Installation
37. INSTALL INSTRUMENT PANEL SUB REINFORCEMENT Installation
38. INSTALL INSTRUMENT PANEL FINISH LOWER PANEL SUB-ASSEMBLY Installation
39. INSTALL NO. 1 SWITCH HOLE BASE Installation
40. CONNECT AIR MIX DAMPER CONTROL CABLE SUB-ASSEMBLY Installation
41. CONNECT NO. 2 HEATER CONTROL CABLE SUB-ASSEMBLY Installation
42. INSTALL AIR CONDITIONING PANEL ASSEMBLY Installation
43. INSTALL SHIFT LEVER ASSEMBLY (for Automatic Transaxle) Installation
44. CONNECT TRANSMISSION CONTROL CABLE ASSEMBLY (for Automatic Transaxle) Installation
45. INSPECT SHIFT LEVER POSITION (for Automatic Transaxle) On-Vehicle Inspection
46. ADJUST SHIFT LEVER POSITION (for Automatic Transaxle) Installation
47. INSTALL SHIFT LEVER ASSEMBLY (for Manual Transaxle) Installation
48. CONNECT TRANSMISSION CONTROL CABLE ASSEMBLY (for Manual Transaxle) Installation
49. ADJUST TRANSMISSION CONTROL CABLE ASSEMBLY (for Manual Transaxle) Adjustments
50. INSTALL INSTRUMENT PANEL FINISH LOWER PANEL Installation
51. INSTALL FRONT NO. 1 CONSOLE BOX INSERT Installation
52. INSTALL FRONT NO. 2 CONSOLE BOX INSERT Installation
53. INSTALL INSTRUMENT CLUSTER FINISH CENTER LOWER PANEL Installation
54. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transaxle) Installation
55. INSTALL COWL SIDE TRIM BOARD RH Installation
56. INSTALL COWL SIDE TRIM BOARD LH Installation
57. INSTALL FRONT DOOR SCUFF PLATE RH Installation
58. INSTALL FRONT DOOR SCUFF PLATE LH Installation
59. INSTALL UPPER INSTRUMENT PANEL SUB-ASSEMBLY Installation
60. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY Installation
61. INSTALL COMBINATION METER ASSEMBLY Installation
62. INSTALL INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY Installation
63. INSTALL INSTRUMENT CLUSTER FINISH LOWER PANEL Installation
64. INSTALL INSTRUMENT CLUSTER FINISH CENTER PANEL SUB-ASSEMBLY Installation
65. INSTALL FRONT PILLAR GARNISH RH Installation
66. INSTALL FRONT PILLAR GARNISH LH Installation
67. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP RH Installation
68. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH Installation
69. INSPECT STEERING PAD Installation
70. INSPECT STEERING WHEEL CENTER POINT
71. CONNECT HEATER OUTLET WATER HOSE Installation
72. CONNECT HEATER INLET WATER HOSE Installation
73. INSTALL AIR CONDITIONING TUBE AND ACCESSORY ASSEMBLY Installation
74. INSTALL SUCTION PIPE SUB-ASSEMBLY Installation
75. CHARGE WITH REFRIGERANT Service and Repair
76. ADD ENGINE COOLANT Service and Repair
77. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
Torque: 5.4 Nm (55 kgf-cm, 48 in-lbf)
78. INSPECT FOR COOLANT LEAK Testing and Inspection
79. INITIALIZE ROTATION ANGLE SENSOR AND CALIBRATE TORQUE SENSOR ZERO POINT
Programming and Relearning
80. INSPECT SRS WARNING LIGHT
Diagnosis System
81. WARM UP ENGINE Service and Repair
82. INSPECT FOR REFRIGERANT LEAK Service and Repair
