Lower A-Pillar Trim, Driver Side

Lower A-Pillar Trim, Driver Side

Removing

- Disengage sill panel trim from body in lower A-pillar trim transition area. Refer to => [ Sill Panel Trim ] Sill Panel Trim.

- Remove side instrument panel covers. Refer to => [ Instrument Panel Side Covers ] Instrument Panel Side Covers.

- Remove center A-pillar trim. Refer to => [ Center A-Pillar Trim ] Center A-pillar Trim.

- Remove the hood release handle - 1 -

- Remove clip - 2 -.

- Remove trim from body - arrow A -.

- Remove trim from door seal piping.

- Pull trim out of mount - arrow B -.

• Before installation, clip - 2 - must be checked for damage and replaced if necessary.






Installing

- Install in reverse order of removal.
