Quarter Upper Trim Panel Replacement

Quarter Upper Trim Panel Replacement

Removal Procedure




1. Remove the lower quarter trim panel. Refer to Quarter Lower Rear Trim Panel Replacement (Quarter Lower Rear Trim Panel Replacement).
2. Disengage the eight retainers and remove the rear quarter upper trim panel.

Installation Procedure




1. Engage the eight retainers and install the rear quarter upper trim panel.
2. Install the lower quarter trim panel. Refer to Quarter Lower Rear Trim Panel Replacement (Quarter Lower Rear Trim Panel Replacement).
