CVT Does Not Shift In Manual Mode

TROUBLE DIAGNOSIS FOR SYMPTOMS


CVT Does Not Shift in Manual Mode


SYMPTOM:
Speed does not change even if the selector lever is put in the manual shift gate position and the selector lever is operated to + side or to - side.

DIAGNOSTIC PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis check. CVT Trouble Diagnosis .
Is any malfunction detected by self-diagnosis?
YES - Check the malfunctioning system. CVT Trouble Diagnosis .
NO - GO TO 2.
2.CHECK MANUAL MODE SWITCH
Check the manual mode switch circuit. P0826 P0826 P0826 P0826 P0826 .
OK or NG
OK - GO TO 3.
NG - Repair or replace damaged parts.
3.CHECK CVT POSITION
Check CVT position. Testing and Inspection
OK or NG
OK - GO TO 4.
NG - Adjust CVT position. Shift Control System.
4.CHECK CVT FLUID LEVEL





Check CVT fluid level. Procedures.
OK or NG
OK - GO TO 5.
NG - Refill CVT fluid.
5.CHECK LINE PRESSURE





Check line pressure at idle. CVT Trouble Diagnosis, "Inspections before
Trouble Diagnosis" .
OK or NG
OK - GO TO 6.
NG - Check the malfunctioning item. CVT Trouble Diagnosis, "Inspections before Trouble Diagnosis" .
6.CHECK SYMPTOM
Check again. CVT Trouble Diagnosis.
OK or NG
OK - INSPECTION END
NG - GO TO 7.
7.CHECK TCM
1. Check TCM input/output signals. CVT Trouble Diagnosis.
2. If NG, re-check TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK - Replace the transaxle assembly. Removal and Installation(MR20DE), Removal and Installation (QR25DE).
NG - Repair or replace damaged parts.
