Home
>>
Isuzu
>>
1988
>>
Impulse L4-2254cc 2.3L SOHC
>>
Repair and Diagnosis
>>
Cruise Control
>>
Cruise Control Module
>>
Locations
>>
Turbo
Turbo
Relay Locations.:
LH Side Of Cowl
Applicable to: 1988 Impulse w/4ZC1 Engine
