Installation

INSTALLATION

FRONT HOSES





1. Install new grommets, if necessary.
2. Connect the new drain hose to the sunroof housing and test drainage.
3. Install headliner Headliner - Installation.
4. Install sunroof opening trim lace.
5. Connect the control switch wire connector and install control switch.
6. Verify sunroof operation and alignment.

REAR HOUSING HOSE





1. Connect the new drain hose to the sunroof housing and test drainage.
2. Install headlinerHeadliner - Installation.
3. Install sunroof opening trim lace.
4. Connect the control switch wire connector and install control switch.
5. Verify sunroof operation and alignment.
