Engine Body, Exposing

Engine body, exposing

Drain the engine oil. Refer to: Oil filter, B6324S5 Service and Repair
Remove the engine. Refer to: Engine, removal, B6324S5 Engine, Removal






Remove the following components:
1. radiator hose
2. front auxiliary unit console
3. console transmission
4. AC-console
5. water pipe







Remove drive flange plate/flywheel. Refer to: Carrier plate, B6324S5, TF-80SC, B6324S5, TF-80SC AWD Service and Repair






Install the following items:
- 999 2520 FLOOR STAND 999 2520 FLOOR STAND
- 999 5297 ENGINE FIXTURE 999 5297 ENGINE FIXTURE
- 998 9721 SCREW SET 998 9721 SCREW SET
