Part 1

Parking assistance, camera, front blind view

INTRODUCTION
- Read through all of the instructions before starting installation.
- Notifications and warning texts are for your safety and to minimize the risk of something breaking during installation.
- Ensure that all tools stated in the instructions are available before starting installation.
- Certain steps in the instructions are only presented in the form of images. Explanatory text is also given for more complicated steps.
- In the event of any problems with the instructions or the accessory, contact your local Volvo dealer.

Parking assistance, camera, front wide angle

Note! Some steps in these installation instructions are presented with illustration only.

- Set the ignition key to position 0.

Note! Wait at least one minute before unplugging the connectors or removing other electrical equipment.

- Disconnect any connector(s).

- Remove the sealing strip.

Caution! Remove the front and upper sill panel as one unit.

- Remove the panel.

- Unplug the connector.

- Release the hooks.

Note! One side at a time.

- Remove the screws.

- Remove the panel.

- Fold the carpet to one side.
- Unhook the clip(s).
- Unplug the connector.

- Remove the panel.

Applies to vehicles with 4C-chassis

- Unplug the connector.

Applies to vehicles with an automatic transmission

- Release the shift-lock function.
- Move the gear selector to position "D".

Applies to vehicles with manual transmissions

- Release the catch that is located inside the boot. Pull the locking sleeve and boot downward. Ensure that the boot does not come loose from the catch.
