Part 2
Connect the connectors.
Tear off the excess foam tape.
Route the cable harness to the existing cable harness.
Route the cable harness to the existing cable harness.
Attach the wiring, using clips.
Pull the wiring through.
Connect the connectors.
Removal
Fold the carpet to the side.
Fold the insulation to one side.
Locate the rubber grommet under the insulation and press it out.
Installation
Note! Do not yet tighten the clamps.
Route the cable harness to the existing cable harness.
Installation
Connect the connectors.
Install the screws.
Removal
Remove the clips.
Remove the screws.
Note! On some markets the rubber grommet may be covered by the heat shield.
Installation
Pull the wiring through.
Caution! Take extra care when handling the component.
Pull the wiring through.
Use: Low temperature grease, 1161427
Removal
Release the catches
Disconnect the connector.
Remove the nuts.
Installation
Pull the wiring through.
Caution! Make sure to locate the wiring in such a way that any damage caused by heat or excessive wear is avoided.
Note! Do not yet tighten the clamps.
Route the cable harness to the existing cable harness.
Note! Do not yet tighten the clamps.
Note! Do not yet tighten the clamps.
Route the cable harness to the existing cable harness.
Note! Do not yet tighten the clamps.
Route the cable harness to the existing cable harness.
Note! Do not yet tighten the clamps.
Caution! Make sure to locate the wiring in such a way that any damage caused by heat or excessive wear is avoided.
Insert the cable in to the passenger compartment, adjust the cable length out into the engine compartment and secure the rubber grommet.
Caution! Tighten clamps properly.
Install the screw.
Connect the connector.
Reinstall the removed parts in reverse order.
Reinstall the battery's negative cable.
Download software (application) for the accessory's function.
