Switch High Pressure

Operation number: 87421-2

Switch high pressure

Removal

Note! Removal steps in this procedure may contain installation details.








Torque: Air conditioning high-pressure switch (steel), 8 Nm

Installation

To install, reverse the removal procedure.

Note! Use new seals.

Caution! Only use the specified material to lubricate the seals.
