Diagnostic Trouble Code (DTC) Information

Diagnostic trouble code (DTC) information CCM-B10E011

Condition
Some of the functions controlled by the buttons on Climate control module (CCM) can also be controlled using a remote control. The remote control uses infrared signals (IR) to transmit commands to the system. Climate control module (CCM) checks the voltage feed to the infrared (IR) sensor located in its panel.
The diagnostic trouble code (DTC) is stored if the control module detects that:
- Power supply missing
The control module's test for the diagnostic trouble code (DTC) starts in the event of:
- Activated control module.





Substitute value
- None.

Possible source
- Short-circuit to ground.

Fault symptom[s]
- Audio other/Keypad on center console does not work
- Remote control/Does not work
