Oil Spray Jet: Service and Repair

Valve, piston cooling

Removal

Note! Removal steps in this procedure may contain installation details.

Remove engine pad right Refer to: Engine support insulator, right, B5254T7 Engine Support Insulator, Right

Torque: M6, 10 Nm

Torque: Piston cooling nozzle, 32 Nm

Installation

To install, reverse the removal procedure.
