Rear Bumper Reinforcement: Service and Repair

Rear bumper rail

Removal

Note! Removal steps in this procedure may contain installation details.

Remove casing bumper rear Refer to: Cover bumper rear Service and Repair

See information about rear piece Refer to: Rear section




Torque: M8, 24 Nm

See information about corrosion protection Refer to: Rustproofing

Installation

To install, reverse the removal procedure.

Perform collision protection unit from behind front seat Refer to: Collision protection unit from behind front seat Collision Protection Unit From Behind Front Seat
