Checking Ground Terminal, Accessory Electronic Module (AEM)
Checking the ground terminal
Checking the ground terminal
- Ignition off
- Control module disconnected
- Switch off all equipment that takes power from the battery (courtesy lighting, radio etc).
Connect the breakout box.
Connect an ohmmeter between terminal #A2 on the breakout box and the battery negative terminal.
The ohmmeter should read 0 ohms.
Other information
- To connect the breakout box, see Connecting the breakout box Connecting the Breakout Box, Accessory Electronic Module (AEM).
Is the value OK?
Yes - FAULT FOUND
No - Checking for open-circuits, contact resistance and oxidation
-------------------------------------------------
Checking for open-circuits, contact resistance and oxidation
Check the ground terminal and the wiring connected to it. Check for an open-circuit.
Check the ground terminal and the wiring connected to it. Check for contact resistance and oxidation.
Other information
- Checking wiring and terminals Checking Wiring and Terminals
Continue - Verification
-------------------------------------------------
Verification
Verification
- Ignition off
- Control module disconnected
- Switch off all equipment that takes power from the battery (courtesy lighting, radio etc).
Connect an ohmmeter between terminal #A2 on the breakout box and the battery negative terminal.
The ohmmeter should read 0 ohms.
Is the value OK?
Yes - VERIFIED
No - VERIFICATION FAILED
------------------------
VERIFIED - FAULT FOUND
VERIFICATION FAILED - Fault-tracing information
-------------------------------------------------
Fault-tracing information
Information
Fault-tracing information
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Do you want to exit fault-tracing?
Yes - Exit fault-tracing
No - Attempt New Test
------------------------
FAULT-TRACING FAILED - No Fault Found
Attempt New Test - Checking the ground terminal
-------------------------------------------------
