Diagnostic Trouble Code (DTC) Information

Diagnostic trouble code (DTC) information ECM-92E0

Condition




The diagnostic trouble code (DTC) is stored if the engine control module (ECM), when attempting to adapt the electronic throttle unit, registers an internal fault in the integrated amplifier for the signal from potentiometer 1 in throttle position sensor (circuit 1) in the electronic throttle unit.

Substitute value
The engine control module (ECM) does not use the signal from potentiometer 1 for the throttle position (TP) sensor (circuit 1) in the electronic throttle unit.

Possible source
- Damaged engine control module (ECM).

Fault symptom[s]
- None.
