Diagnostic Trouble Code (DTC) Information

Diagnostic trouble code (DTC) information ECM-911C

Condition




The diagnostic trouble code (DTC) is stored if the engine control module (ECM) receives a fault message from the central electronic module (CEM), via the controller area network (CAN), indicating a faulty signal from the clutch pedal position sensor or a fault in the CAN communication.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.

Substitute value
Cruise control switched off.

Possible source
- Fault-trace the central electronic module (CEM).

Fault symptom[s]
- Cruise control does not function at all.
