DIM-0001

Diagnostic trouble code (DTC) information DIM-0001

Condition




The diagnostic trouble code (DTC) is stored if the driver information module (DIM) registers that the stored mileage value differs by more than 500 km from the most recently stored mileage.

Hint: The diagnostic trouble code (DTC) can also be generated if there is a communication fault with the brake control module (BCM). Fault trace following CEM-DE01 Communication with brake control module (BCM), signal missing.

Substitute value
- Nothing.

Possible source
- Software fault in the control module.
- Communication fault with brake control module (BCM).

Fault symptom[s]
- No symptom.
