Diagnostic Trouble Code (DTC) Information

Diagnostic trouble code (DTC) information CEM-6F13

Condition




The central electronic module (CEM) communicates with the sun roof module (SRM).
The diagnostic trouble code (DTC) is stored if the central electronic module (CEM) registers a short-circuit to battery voltage in the global opening / closing circuit for the sun roof.
The diagnostic trouble code (DTC) can be diagnosed at key positions I and II.

Substitute value
- None.

Possible source
- Short-circuit to battery voltage in the signal cable.

Fault symptom[s]
- Automatic sun roof closure does not function.
