Engine, Removal

Engine, removal

Operation number: 21040-2

Removal

Perform depressurizing fuel system Refer to: Fuel system pressure release, B6304T4, B6324S5, B6324S4 Fuel System Pressure Release

Drain cooling system, draining, filling, and bleeding Refer to: Cooling system - draining, charging and bleeding, B6304T4, B6324S5, B6324S4 Service and Repair

Loosen A/C-compressor Refer to: AC compressor, B6304T4 Service and Repair

Remove the following items:
- Engine control module (ECM) Refer to: Engine control module (ECM), B6304T4, B6324S5, B6324S4 Service and Repair
- thermostat Refer to: Thermostat, B6304T4 Service and Repair
- the catalytic converter Refer to: Catalytic converter, B6304T4, TF-80SC AWD Service and Repair
- Upper torque rod Refer to: Upper torque rod, B6304T4, B6324S5, B6324S4 Service and Repair
- Drive shaft right Refer to: Drive shaft right, B6304T4, TF-80SC AWD, B6324S4, TF-80SC, B6324S4, TF-80SC AWD, B6324S5, TF-80SC AWD, B6324S5, TF-80SC Driveshaft Right
- Driveshaft left Refer to: Driveshaft left, B6304T4, TF-80SC AWD, B6324S4, TF-80SC, B6324S4, TF-80SC AWD, B6324S5, TF-80SC AWD, B6324S5, TF-80SC Driveshaft Left
- Front subframe Refer to: Front subframe, B6304T4, TF-80SC AWD, B6324S4, TF-80SC, B6324S4, TF-80SC AWD, B6324S5, TF-80SC AWD, B6324S5, TF-80SC Service and Repair
- bevel gear Refer to: Bevel gear, B6304T4, TF-80SC AWD, B6324S4, TF-80SC AWD, B6324S5, TF-80SC AWD Bevel Gear

Note! Use suitable paper to absorb any escaping fluid.

Caution! Make sure that no components catch.

Use: Unit lift.

Remove the following items:
- Engine support insulator, right Refer to: Engine support insulator, right, B6304T4, TF-80SC AWD, B6324S4, TF-80SC, B6324S4, TF-80SC AWD, B6324S5, TF-80SC AWD, B6324S5, TF-80SC Engine Support Insulator, Right
- Engine support insulator left Refer to: Engine support insulator left, B6304T4, B6324S5, B6324S4 Engine Support Insulator Left
