Audio System - HD Radio(R) Troubleshooting Guidelines

Retailer Technical Journal 20784
HD Radio Troubleshooting Guidelines
Date 03-19-2009

REFERENCE: Owner's manual

Note!
If using a printed copy of this Retailer Technical Journal, first check for the latest online version.





AFFECTED VEHICLES:














DESCRIPTION:
The following document was drafted to explain the operation and concepts of HD Radio Technology to the technician in hopes of avoiding improper diagnosis leading to unnecessary parts replacements. Materials provided by iBiquity are subject to copyright and are reproduced here with permission.
