Wiper Mechanism, Windshield, R.H.D

Wiper mechanism, windshield

Operation number: 36320-2

Removal

Note! Removal steps in this procedure may contain installation details.





Remove the plenum cover Refer to: Plenum chamber Service and Repair




Torque: M6, 10 Nm

Installation

To install, reverse the removal procedure.
