Rear Center Seat Backrest






Rear Center Seat Backrest

Operation number: 85310-2

Removal

Remove back cushion outer rear seat Refer to: Seat Cushion, Rear Seat

Remove the head restraint Refer to: Upholstery middle head restraint rear Upholstery Middle Head Restraint Rear













Installation

To install, reverse the removal procedure.
