Fault-Tracing

Fault-tracing

Replacing a component
The Central electronic module (CEM) has registered a mechanical fault in the Steering wheel module (SWM).
Replace the Steering wheel module (SWM).
Remedy as necessary.

Other information:





Continue - Verification

-------------------------------------------------

Information




Information

Fault-tracing information
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Do you want to exit fault-tracing?

Yes - Exit fault-tracing

No - Attempt New Test

------------------------

Attempt New Test - Replacing a component

-------------------------------------------------

Verification

Hint: After carrying out the repair, check that the fault has been remedied.




- Ignition off.
- Reinstall the connectors, components etc.
- Ignition on.
Check that the function is now OK.

Are the controls working?

Yes - Troubleshooting procedure complete

No - Information

-------------------------------------------------
