Seat Belt Buckles, Auxiliary Rear Facing Seat, Replacing






Seat belt buckles, auxiliary rear facing seat, replacing

Removing the seat belt buckle




- Remove the two screws (2)
- During delivery: Remove the transport protectors (1).

Installing the seat belt buckle
- Install the two screws (2).
