Engine, Removal

Engine, removal

Removal

Perform depressurizing fuel system Refer to: Fuel system pressure release, B5244S4 Fuel System Pressure Release

Drain cooling system, draining, filling, and bleeding Refer to: Cooling system - draining, charging and bleeding, B5244S4 Service and Repair

Remove the following items:
- battery
- air cleaner (ACL) housing Refer to: Air cleaner housing Service and Repair
- Tensioner accessory drive belt
- Bracket lower torque rod Refer to: Bracket lower torque rod, B5244S4 Bracket Lower Torque Rod
- Front subframe
- the catalytic converter Refer to: Catalytic converter Service and Repair
- Drive shaft right
- Driveshaft left
- right-hand side fog lamp front Refer to: Front fog lights Removal and Replacement Front fog lights Removal and Replacement

981 4123 Spanner 981 4123 Spanner

Note! Use suitable paper to absorb any escaping fluid.

999 7077 Jimmy bar 999 7077 Jimmy Bar

Note! Use suitable paper to absorb any escaping fluid.

Warning! Be prepared to collect escaping fluid.

Use: Unit lift.

Remove the following items:
- Engine support insulator, right Refer to: Engine support insulator, right, B5244S4 Engine Support Insulator, Right
- Engine support insulator left Refer to: Engine support insulator left Engine Support Insulator Left

Caution! Take extra care when handling the components.

Note! Make sure that no components catch.
