Label Information

LABEL INFORMATION

1. Vacuum hose routing (underside of hood)

2. Model plate
Vehicle Identification Number (VIN).
Codes for color and upholstery, etc. The label is located on the passenger's side center door pillar.

3. Loads and Tire Pressures
(on inside of fuel filler door): Canadian models only.

4. Child safety lock
This information is stamped on the rear inside edges of the doors.

5. Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada)
Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the facing side of the driver's door. For further information regarding these regulations, please consult your Volvo retailer.

6. Loads and Tire Pressures U.S. models only
Certain models will only have one decal, depending on the specifications of the vehicle.

7. Vehicle Identification Number (VIN) *1
The VIN plate is located on the top left surface of the dashboard. The VIN is also stamped on the right hand door pillar.

8. Vehicle Emission Control Information
Your Volvo is designed to meet all applicable emission standards, as evidenced by the certification label on the underside of the hood. For further information regarding these regulations, please consult your Volvo retailer.

*1: The Vehicle Identification Number (VIN) should always be quoted in correspondence concerning your vehicle with the retailer and when ordering parts.
