R.H.D

Bushing, push rod, replacing

Preparations for replacement





Remove:
- the soundproofing panel. See Master cylinder, replacing, B5254T2, M58, B5244T5, M66, B5254T2, M56 R.H.D.
- the clip for the push rod at the brake pedal
- the old bushing for the push rod which is on the bracket.

Install the new bushing





Install
- the bushing. Lubricate with grease. P/N 1161241-3
- the clip and push rod on the brake pedal
- the soundproofing panel.
