BCM-0119

BCM 0119 Power Supply for the Active Yaw Control Sensor (Voltage too high)

Condition





Note: The Diagnostic Trouble Code (DTC) applies only to cars with Dynamic Stability and Traction Control (DSTC).

Diagnostic Trouble Code (DTC) BCM-0119 is stored if the Brake Control Module (BCM) registers that the power supply to the active yaw control sensor is below 6 V +0.5 V.

Substitute value
- Traction control is blocked
- Stability control is blocked
- Active yaw control is blocked.

Hint: For information about abbreviations, see Brake system abbreviations.

Possible Source
- Contact resistance in the terminals on the active yaw control sensor
- Short-circuit to ground in the wiring
- Open-circuit in the wiring
- Internal fault in the active yaw control sensor
- Internal fault in the Brake Control Module (BCM).

Fault symptom[s]
- The anti-spin warning lamp is lit (up to and including 2002 model year)
- General yellow warning lamp lit (from 2003)
- Anti-spin does not function
- The stability control system does not function
- The traction control system does not function.
