Signal Too High - Intermittent Fault

Intermittent Fault







Check the wiring between transmission control module (TCM) terminal #4 and terminal #5 on the 8-pin transmission connector. Check the wiring between control module terminal #32 and transmission connector terminal #6.

Check for an intermittent short-circuit to supply voltage according to Checking wiring and terminals. Intermittent faults.

HINT: Check solenoid SLS by measuring the resistance between terminals #5 and #6 on transmission connector. The ohmmeter should read 5 - 5.6 Ohms at 20 degree C.

Remedy as necessary.

Other information:
- To connect the breakout box, see Connecting the breakout box.
- To disconnect the transmission control module (TCM), see Transmission control module (TCM), replacing.
- To disconnect the transmission connectors, see Transmission connectors.
- For information about signals, see Signal description. Transmission control module (TCM).

Select Continue when the fault has been remedied.

Continue with Next Procedure. Fault-Tracing Information - Intermittent Fault
