Signal Too High. Intermittent Fault

Signal too high. Intermittent fault

Checking the wiring
Check the wire between central electronic module #9A and light width control actuator 6/38 LH, and 6/39 RH actuator #2 for a short circuit to voltage supply as described in Checking wiring and terminals. Intermittent faults Checking Wiring and Terminals. Intermittent Faults.
Do the necessary corrective action

Additional information:
- For information on the central electronic module (CEM), see Central electronic module (CEM), replacing Central Electronic Module (CEM), Replacing.














Continue - Trouble-shooting information

-------------------------------------------------

Trouble-shooting information




Information

Fault-tracing information
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Do you want to view the information again?

Yes - Attempt New Test

No - Fault Found

------------------------

Attempt New Test - Checking the wiring

FAULT FOUND - DONE

-------------------------------------------------
