SRS-006B

Condition







If the circuit capacitance is low for more than 10 sec, diagnostic trouble code SRS-006B is displayed.

Substitute value

- Nothing.

Possible source

- Capacitance too low in connector.
- Capacitance too low in the signal wire between seat-belt tensioner and the supplemental restrain system (SRS).

Fault symptom[s]

- SRS warning lamp on.
