SRS-0045

Condition







If the circuit resistance is too low for more than 10 seconds, diagnostic trouble code SRS-0045 is displayed.

Substitute value

- Nothing.

Possible source

- Short circuit in igniter wire or connectors between the front right side air bag and the supplemental restraint system (SRS) control unit.
- Short circuit in the front right side air bag (resistance in igniter too low).

Fault symptom[s]

- SRS warning lamp on.
