SRS-0015

Condition







If the control unit registers that the resistance in the circuit is too low for more than 10 seconds, diagnostic trouble code SRS-0015 is displayed.

Substitute value

- Nothing.

Possible source

- Short circuit in igniter wire or in the connectors between the air bag and the supplemental restraint system (SRS).
- Short circuit to air bag (resistance in igniter too low).
- Short circuit in contact reel.

Fault symptom[s]

- SRS warning lamp on.
