SWM-0024

Condition







If SWM microprocessor/control unit registers that RTI Up button is activated for more than 5 minutes, diagnostic trouble code SWM-0024 is displayed.

Substitute value

- Nothing.

Possible source

- RTI Up button is activated for more than 5 minutes.

Fault symptom[s]

- RTI settings change without RTI buttons being activated manually.
- RTI steering wheel buttons do not work.
