SWM-0022

Condition







If SWM microprocessor/control unit registers that RTI Enter button is activated for more than 5 minutes, diagnostic trouble code SWM-0022 is displayed.

Substitute value

- Nothing.

Possible source

- RTI Enter button is activated for more than 5 minutes.

Fault symptom[s]

- RTI steering wheel buttons do not work.
