DTC ECM-1000

Condition
If the control module registers that a signal from the internal atmospheric pressure sensor is faulty, the control module interprets this as a fault and ECM-1000 is stored after 20 seconds.







Substitute value
The control module assumes 1013 hPa air pressure corresponding to sea level.

Possible source
Signal too high:
- defective control module

Signal too low:
- defective control module

Fault symptom[s]
- Malfunction indicator lamp (MIL) lit.
