BCM-0065

BCM 0065 Stop Lamp Switch (Faulty Signal)

Condition





Note: Only applies to four wheel drive cars with TRACS (traction control system). The brake control module compares the signals with each other in order to detect a faulty signal from the stop lamp switch or the pedal position sensor. Diagnostic Trouble Code (DTC) BCM-0065 is stored if the control module registers a faulty signal from the stop lamp switch or the pedal position sensor.

Substitute value
- Traction control is blocked.

Hint: For information about brake system abbreviations, see Brake system abbreviations.

Possible Source
- Short-circuit to ground or supply voltage in the signal cable for the stop lamp switch
- Defective stop lamp switch
- Defective pedal position sensor.

Fault symptom[s]
- Anti-spin does not function.
