ABS-00C3

DTC ABS-00C3 Reversing Signal

Condition

Note: This diagnostic trouble code applies only to ABS systems equipped with DSTC.





If the ABS control unit registers that the reversing signal is missing, diagnostic trouble code ABSOOC3 will be stored.

Substitute value
- Anti-spin function blocked.
- Stabilizing function blocked.

Possible source
- TBD.
- TBD.

Fault symptom[s]
- Anti-spin does not work.
- Stabilizing function not working.
- Anti-spin warning lamp is on.
