ABS-00C0

DTC ABS-00C0 Stabilizing Function

Condition

Note: The diagnostic trouble code (DTC) applies only to ABS systems equipped with dynamic stability and traction control (DSTC).





Diagnostic trouble code (DTC) ABS-00C0 is stored if the control module registers that the stability function is engaged for too long.

Substitute value
- The anti-spin function is blocked
- The stability function is blocked.

Possible source
- The steering wheel angle is incorrect by more than 15°.

Fault symptom[s]
- Anti-spin does not function
- No stability function
- Anti-spin warning lamp lit.
