ABS-0066

DTC ABS-0066 Front Brake Discs

Condition





On cars with anti-spin, the control module registers brake usage and calculates front wheel brake discs temperatures. The diagnostic trouble code (DTC) ABS-0066 is stored if the calculated temperature exceeds 450°C (842°F).

Substitute value
- ABS function not affected.
- Anti-spin function blocked.

Possible source
- Anti-spin control in action too long.
- Brakes on too long (brakes have been used so much that brake disc temperature has become too high).

Fault symptom[s]
- ABS warning lamp lit.
- Anti-spin warning lamp lit.
- Anti-spin does not function.

Note: Anti-spin function is deactivated until brake disc temperature is below 350°C (662°F).
