Front-Rear Adjustment Motor (Center Motor)

Front-rear adjustment motor (center motor)

Preparations
Remove:
- the seat from the car.
- the connectors.

Removing the center motor







Remove:
- two screws (A).
- the motor.

Install:
- In reverse order.

Tightening torque for the seat to the floor: 48 Nm.
