Partial Adjustment of the Window Top Edge

PARALLEL ADJUSTMENT OF THE WINDOW TOP EDGE, POWER WINDOW, FRONT AND REAR

The top of the window should be parallel with the door arch.






- Slacken off nut A. Adjust the window vertically. Upper illustration: Front door Lower illustration: Rear door
- Tighten nut
- Check that the upper edge of the window is parallel with the door arch edge.
Adjuster nut hole (A) can be filed up if further adjustment is necessary.






MORE ADJUSTMENT REQUIRED:
Slacken off power window lift mechanism cassette screws.
Adjust cassette downwards at the rear edge.
