Checking the Neutral Check

Checking The Neutral Check







- Ignition off
- Check the transmission and control module connectors. Check for contact resistance and oxidation according to Checking wiring and terminals. Permanent faults
- Reconnect the connectors, reinstall components etc.
- Raise the car so that the drive wheels can rotate freely
- Start the car
- Move the gear selector to position D. Accelerate so that the speed exceeds 50 km/h
- Brake the wheels and let the engine run at idling speed without touching the accelerator pedal (AP). The neutral check should display the "Active" status (this may take up to 30 seconds)
- Brake the wheels. Move the gear selector to position D. Carefully depress the accelerator. Check that the neutral check changes to the "Inactive" status.

Check that the function operates in gear positions 4, 3 and 2.

Does the status change?

YES: Refer to Trouble Code Descriptions. Diagnostic Trouble Code Descriptions
NO: Continue with Next Procedure. Refer to Checking Shift Solenoids S1 And S2.
