Checking The Wiring And Component

Checking The Wiring And Component










- Ignition off.
- Open the transmission control system.

Check that there is no metal swarf or dirt in the control system. Replace solenoid S3 if the control system is OK.

Replace the transmission if there is any metal swarf in the control system.

Remedy as necessary.

Other information:
- To open the control system and to check or replace solenoid S3, see Solenoid control system, replacing.
- For information about signals, see Signal description. Transmission control module (TCM).

Is there any metal swarf in the transmission?

YES: Continue with Next Procedure. Replacing The Transmission
NO: Refer to Resetting Adaptation And The Counter For "Transmission Oil Change". Resetting Adaptation And The Counter For "Transmission Oil Change"
