Diagnostic Trouble Code (DTC) Information

Diagnostic Trouble Code (DTC) Information







Condition
Diagnostic trouble code (DTC) SRS-112 is stored if the on-board diagnostic system has stored a fault in any of the internal control module functions

Possible source
- Internal fault in the control module.

Condition
- The SRS indicator lamp lights


WARNING
There is a risk that the SRS Will not function if this diagnostic trouble code (DTC) stored.


NOTE: Diagnostic trouble code (DTC) SRS-112 must not be erased if it occurs during the warranty period. In such cases the control module must be returned to Volvo according to standard procedures.


NOTE: No other diagnostic trouble codes (DTC) can be erased if DTC SRS-112 is stored.
