Diagnostic Trouble Code (DTC) Information

ECM-268A LONG-TERM FUEL TRIM
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION




Condition
The control module receives information from the heated oxygen sensor (HO2S) about fuel/air mixture - If the fuel/air mixture deviates from [lambda]=1 the short-term fuel trim will compensate for this by adjusting injection time so that [lambda]=1 is achieved. Diagnostic Trouble Code (DTC) ECM-268A will be stored if the short-term fuel trim deviates too much from its central position (value) when long-term fuel trim diagnostics are activated.

Condition
none

Possible source

Upper limit
- intake air leakage
- exhaust system air leakage
- low fuel pressure

Lower limit
- intake air leakage
- high fuel pressure
- leaking injectors
- defective mass air flow (MAF) sensor
- contaminated engine oil
- oil level too high

Condition
- none
