Paintwork Repairs






Paint Work repairs



















































Plastic components - painting Europe (Du Pont)
Centari painting system for plastic is a very simple, easy-to-use system to paint most normal hard, semi-hard and soft plastic components on cars.
Products:
800R Bonding primer
Always apply 800R Centari Flexible Sealer. Allow to evaporate for 5 minutes between layers. Wait a further 15 minutes before applying further layers.
805R softener
Is mixed with :
- 1020R HS Primer
- Centari 500
- 600S - 690S - AX1060 Clearcoats
Plastic material:
PP/EPDM PA
GRP PBT
BMC PUR
SMC PVC
ABS PPO
PC

USA
Plastic repairs:
