Diagnostic Trouble Code (DTC) Information

Diagnostic Trouble Code (DTC) Information







Condition
If the Control module registers that there is an internal fault in the ultrasonic sensor own control module when: the alarm system is powered up or the alarm is activated/deactivated, then diagnostic trouble code (DTC) GLA-414 is stored after approximately 2 seconds.

Condition
None.

Possible source
- Defective ultrasonic sensor

Condition
- The indicator LED flashes for 15 seconds when the ignition is switched on.
- The system will not trigger the alarm if there is movement in the passenger compartment
