Diagnostic Trouble Code (DTC) Information

ECM-9200 CRUISE CONTROL
DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION




Condition
Diagnostic Trouble Code (DTC) ECM-9200 is stored in the Engine Control Module (ECM) if the Engine Control Module (ECM) registers a fault in the signal from the cruise control switch.

Condition
Cruise control shut off.

Possible source

Signal too high:
- one or more of the signal cables from the cruise control switch is short-circuited to supply voltage.

Faulty signal:
- defective cruise control switch.

Condition
- ETS warning lamp lit
- cruise control does not function at all.
