Fuel Filter: Service and Repair

Fuel filter, replacement

Draining the fuel system




- Drain the fuel system, see Service and Repair.

Removing the fuel filter




Detach the snap-on couplings from the fuel filter, using a 17 mm wrench to retract the sleeves.
- Undo the bolt holding the clamp round the filter.
- Change the filter.
Refit in reverse order.
